PCB ROUTERS

Trusted by the Aerospace & Defense Industry for over 47 years



Fancort offers a wide choice of PCB routers, including two desktop models that are available with twin tables for increased through-put.



USA SUPPORTED

SHIPPED FROM USA

5 STAR RATED

Serving the industry since 1973

AEROSPACE QUALITY

Trusted by the aerospace & defense industry

Worldwide Shipping

We ship our equipments globally

SHOP OUR PCB ROUTERS

FR-1000 STAND ALONE PCB ROUTER

FR-1000 STAND ALONE PCB ROUTER

Introducing Fancort's FR-1000 stand alone collaborative ready PCB router machine, specially designed as a low cost solution to meet medium volume PCB depaneling requirements with a machine that provides the mechanical properties necessary for reliable accurate depaneling.

The FR-1000 is capable of depaneling boards up to 406mm x 444mm and up to 3 mm thick.

FEATURES

  • Large panel size: 406mm x 444mm.
  • Powerful gantry system.
  • Easy vision jog and teach programming.
  • Small overall footprint.
  • Vac filtering for ultra clean operation.
  • Fiducial mark vision alignment.
  • Vision based bar code and pattern recognition program selection.
  • Manufactured in the USA/NJ by Fancort Industries, backed with one year warranty.
  • Quick release for fast bit changeover.
  • Fixture comes standard equipped as a universal fixture but can also easily accept dedicated tooling for fast change over for mixed environments.
  • Optional pneumatic automatic door to help input and output of the material either by a collaborative robot or by the operator.

Technical Specs

Manipulator
Configuration: X, Y, & Z axis.
Manipulator Repeatability: ±0.02mm.

Routing Capability
Non routing speed: 800 mm/s.
Routing speed: up to 25mm/s max depending on material, cutting quality and tool diameter.
Repeatability: <±0.02mm straight lines, curves & interpolated profiles.

Workstation
Panel Location: Adjustable fixture with ability to add dedicated fixture plates.
Loading: Manual or Collaborative Robot Loading.
Panel Size: 406mm x 444mm (16” x 17.5”).
Panel Thickness: 0.5 mm – 3.0 mm.

Spindle System
Spindle Motor: 350 Watt High Power Spindle.
Max Speed: 60,000 rpm.
Tool Change: Manual tool change.
Router Bit: Shank size 3.175 mm (1/8”).

Dust filtration system
Power: 1.0 KW vacuum blower with HEPA filter.
Filtration: 3 stage filtration with disposable filter bag (10 microns).
Vacuum Location: Top vacuum on spindle.

Vision System
High resolution CCD video teaching camera.
Fiducial correction.
High quality touch screen monitor GUI standard.

Programming
On line: Vision assisted point to point manual teaching.
Editing Function: Dry run vision assisted/test run mode.
Variable Functions: Tool bit diameter compensation, Filter change interval (distance) setting.
Gerber File Import with PC software for offline programming.

Safety Features
Full steel interlocked enclosure for noise, dust, and operator safety.

Machine Dimensions & Utilities
Machine size: 1.00 M x 1.00M x 1.8M.
Weight: 300 kg.
Power Supply: 120/1/60 V for machine and separate Vacuum.

Options:

  • Dedicated Fixture Plates.
  • High Power Vacuum.
  • Gerber File Import.
  • Cobot Mounting Station.
  • Pneumatic Automatic Door.

STAND ALONE PCB ROUTERS


STAND ALONE PCB ROUTERS

Stand alone router machines specially designed to depanelize printed circuit board assemblies (PCBA) into individual assemblies.

  • Semi Automatic Router Machine: GSR2280
  • Semi Automatic Router Machine: GSR

INLINE PCB ROUTERS


INLINE PCB ROUTERS

In-Line PCB Production: Machinery designed for in-line PCB production and continuous operation.

PCB thickness up to 8 mm with automatic offload to downstream conveyance systems.

  • Bottom Router: GBR
  • Ge-tech Automatic Router Machine: GAR1200
  • Inline Router with Board Handling Machine: RBM
  • Inline Dicing Machine: IDM

JR2300 DESKTOP DEPANELING ROBOT

JR2300 DESKTOP DEPANELING ROBOT

Fancort offers two desktop models that are available with twin tables for increased through-put.

The two desktop routers only differ in the use of fixtures.

The "up-vac" model can use our adjustable fixture making it ideal for CM's with a high mix of panels.

The "down-vac" model is designed for use with dedicated fixtures where the production runs are longer, there is no time lost in fixture set-up, and no risk of an operator making the wrong set-up.



FEATURES

  • Reduces the stress on PC Boards
  • Router Cutting Method
  • Vacuum system for Down Vac version sits under the board support fixture for removing debris and dust.
  • High precision spindle motor performs stress free cutting for smooth and easy depaneling.
  • Cuts straights lines, curves and angles.
  • Fancort will design and build your fixtures
  • For in-line applications, a SCARA routing system is available
  • Optional enclosure available
  • Tool Offset Function
  • You can incorporate CAD for easy and precise cutting.
  • Easy router positioning
  • USB Camera Teaching (Optional)
  • Set points using a camera image on your PC screen.
