RA-18 UNIVERSAL PCB RACKS

Trusted by the Aerospace & Defense Industry for over 47 years

RA-18 Universal PCB Racks

Typewriter effect
Please refer to the table below to compare differences and applications that Fancort Universal Racks deliver.
FEATURES RA-18 C RA-18 CT RA-18 HT RA-18 CTD RA-18 HTD RA-18 CD RA-18 C/SMT RA-18 CL RA-18 SDG

Stackable

Customizable

Works for PCB Storage

Carrying Handle

ESD - SAFE

Double Wide Available

Clean Room

High Temp Rated

Max Temperature

185°F = 85°C

185°F = 85°C

275°F = 135°C

275°F = 135°C

275°F = 135°C

185°F = 85°C

163°F = 73°C

163°F = 73°C

185°F = 85°C

Max PCB Size (W")

Single Wide 8"

Single Wide 8"

Single Wide 8"

Double Wide 24"

Double Wide 24"

Double Wide 24"

Single Wide 8"

Single Wide 8"

Single Wide 8"

Min PCB Size

Single Wide 2"

Single Wide 2"

Single Wide 2"

Single Wide 2"

Single Wide 2"

Single Wide 2"

Single Wide 2"

Single Wide 2"

Single Wide 2"

Amount of Slots

25 Slots

25 Slots

25 Slots

25 Slots

25 Slots

25 Slots

25 Slots

25 Slots

25 Slots

Color Available
Typewriter effect
Please select a model from the TAB panel below.

Universal Rack RA-18

UNIVERSAL RACK TO HANDLE AND PROCESS PCB BOARDS

  • Dimensions 6" x 18", weights 0.5 lb.
  • 25 slots with parallel sides for more rigid holding, 0.125" x 0.300 on a 0.625" pitch.
  • For bare board processing tolerates acids, alkaline and solvents
  • Black Standard Conductive (185ºF)
  • ESD-SAFE
  • The rack is light, economical, yet ruggedly designed with cross ribbing to maintain flatness.
  • Can hold boards with components as close as .150” from the edges

Model RA-18

Universal Rack RA-18 CT

UNIVERSAL RACK TO HANDLE AND PROCESS PCB BOARDS

  • Dimensions 6" x 18", weights 0.5 lb.
  • 25 slots with parallel sides for more rigid holding, 0.125" x 0.300 on a 0.625" pitch.
  • High temperature conductive model for bare board processing tolerates acids, alkaline and solvents
  • Black High Temp Conductive (275ºF)
  • The rack is light, economical, yet ruggedly designed with cross ribbing to maintain flatness.
  • Can hold boards with components as close as .150” from the edges
  • ESD-SAFE



Model RA-18

Universal Rack RA-18 HT

UNIVERSAL RACK TO HANDLE AND PROCESS PCB BOARDS

  • Dimensions 6" x 18", weights 0.5 lb.
  • 25 slots with parallel sides for more rigid holding, 0.125" x 0.300 on a 0.625" pitch.
  • High temperature conductive model for bare board processing tolerates acids, alkaline and solvents
  • Black Very High Temp Polysulfone (275ºF) Non-ESD
  • The rack is light, economical, yet ruggedly designed with cross ribbing to maintain flatness.
  • Can hold boards with components as close as .150” from the edges

Model RA-18

Universal Racks RA-18 CTD

 UNIVERSAL RACK TO HANDLE AND PROCESS PCB BOARDS

  • Dimensions 18" x 18", weights 1.5 lb.
  • 25 slots with parallel sides for more rigid holding, 0.125" x 0.300 on a 0.625" pitch.
  • High temperature conductive model for bare board processing tolerates acids, alkaline and solvents
  • Black Double Wide Conductive High Temp (275ºF)
  • ESD-SAFE
  • The rack is light, economical, yet ruggedly designed with cross ribbing to maintain flatness.
  • Can hold boards with components as close as .150” from the edges
  • Double wide models expand to hold boards up to 24" wide with a carrying handle
  • Double wide structure made of aluminum extrusion. Finish: Natural Anodize

Model RA-18

Universal Racks RA-18 HTD

 UNIVERSAL RACK TO HANDLE AND PROCESS PCB BOARDS

  • Dimensions 18" x 18", weights 1.5 lb.
  • 25 slots with parallel sides for more rigid holding, 0.125" x 0.300 on a 0.625" pitch.
  • High temperature conductive model for bare board processing tolerates acids, alkaline and solvents
  • The rack is light, economical, yet ruggedly designed with cross ribbing to maintain flatness.
  • Can hold boards with components as close as .150” from the edges
  • Double wide models expand to hold boards up to 24" wide with a carrying handle
  • Double wide structure made of aluminum extrusion. Finish: Natural Anodize
  • Black Double Wide, non-conductive. Very High Temp (275ºF)

Model RA-18

Universal Racks RA-18 CD

UNIVERSAL RACK TO HANDLE AND PROCESS PCB BOARDS

  • Dimensions 18" x 18", weights 1.5 lb.
  • 25 slots with parallel sides for more rigid holding, 0.125" x 0.300 on a 0.625" pitch.
  • Standard temperature conductive model for bare board processing tolerates acids, alkaline and solvents
  • Double Wide/ Standard Temperature ESD-Safe (185ºF)
  • ESD-SAFE
  • The rack is light, economical, yet ruggedly designed with cross ribbing to maintain flatness.
  • Can hold boards with components as close as .150” from the edges
  • Double wide models expand to hold boards up to 24" wide with a carrying handle
  • Double wide structure made of aluminum extrusion. Finish: Natural Anodize

Model RA-18

Universal Racks RA-18 C/SMT

UNIVERSAL RACK TO HANDLE AND PROCESS PCB BOARDS

This rack has been designed to solve a growing industry problem which is holding circuit boards with parts closer to the edge than conventional carriers can handle. The rack is light, and economical, yet ruggedly designed with cross ribbing to maintain flatness.

  • Dimensions 6" x 18", weights 0.5 lb.
  • 25 slots with parallel sides for more rigid holding, 0.125" x 0.300 on a 0.625" pitch.
  • High temperature conductive model for bare board processing tolerates acids, alkaline and solvents
  • Tolerates (163ºF)
  • ESD-SAFE
  • Blue For those boards with components near the edge; slot size .075" x .125" on .500" pitch
  • Clean Room material and Static-Dissipative

Model RA-18

Universal Racks RA-18 CL Cleanroom Rack

UNIVERSAL RACK TO HANDLE AND PROCESS PCB BOARDS

  • Dimensions 6" x 18", weights 0.5 lb.
  • 25 slots with parallel sides for more rigid holding, 0.125" x 0.300 on a 0.625" pitch.
  • ESD-SAFE
  • Blue Cleanroom material and static-dissipative (163ºF)
  • RA-18CL Clean Room material and Static-Dissipative
  • Permanently static dissipative
  • Humidity insensitive
  • Ultra-Clean: Low off-gassing, low contamination
  • Durable
  • Applications: Semiconductor handling. PCB handling in cleanroom environments.

Model RA-18

Universal Racks RA-18 SDG

UNIVERSAL RACK TO HANDLE AND PROCESS PCB BOARDS

  • Dimensions 6" x 18", weights 0.5 lb.
  • 25 slots with parallel sides for more rigid holding, 0.125" x 0.300 on a 0.625" pitch.
  • High temperature conductive model for bare board processing tolerates acids, alkaline and solvents
  • ESD-SAFE
  • Made with Stat-Rite®X-5356Green
  • RA-18SDG Green static dissipative material for lead-free boards (185ºF)
  • Ultra-clean: low off-gassing, low ionic contamination
  • Humidity insensitive



Model RA-18
